ZR30 Electro-Optical Pod
Product Description
The ZT30 is a four-sensor hybrid pod that efficiently integrates a zoom camera, thermal imaging camera, laser rangefinder, and wide-angle camera. It is equipped with a 640x512 high-resolution thermal imaging sensor, a 1200-meter high-precision laser rangefinder, 180x hybrid zoom, and 30x optical zoom (1/2.7-inch Sony CMOS supporting 4K-level video recording and photography). It can be optionally equipped with the powerful BORAN self-developed AI recognition and tracking function, a 2K ultra-wide angle, unlimited rotation along the heading axis, and an upgraded shock-absorbing quick-release structure. The gimbal features a rich set of control interfaces, compatible with both BORAN link products and third-party link devices. The high-precision, highly coordinated control algorithm ensures stable zooming and imaging effects during flight.
Equipment Features
1.180× Hybrid Zoom
2.30× Optical Zoom
3.4K Ultra HD Video & Photo
4.8MP (8 Megapixels) 1/2.7-inch Sony CMOS
5.Nose Mode
6.Pan Axis 540° Rotation Range
7.Ardupilot & PX4 Compatible (Mavlink)
8.Ethernet, HDMI, CVBS Video Output
9.High-Precision & High-Coordination Control Algorithm Inverted Mode
Technical Specifications
|
Category |
Parameter Details |
|
Zoom Camera |
Lens: 30x Optical Zoom (180x Hybrid Zoom) |
|
TF Card Video Recording Resolution: |
|
|
- 4K (4096×2160) @ 25 fps |
|
|
- 2K (2560×1440) @ 30 fps |
|
|
- 1080p (1920×1080) @ 30 fps |
|
|
- 720p (1280×720) @ 30 fps |
|
|
Image Sensor: 1/2.7 inch CMOS, Effective Pixels: 8 million |
|
|
Quick-release Structure |
Supported |
|
Gimbal Horizontal Rotation Range |
-270° ~ +270° |
|
Video Output Signal Interface |
Ethernet, Micro-HDMI |
|
Control Signal Input Method |
S.Bus, UART, Ethernet (UDP) |
|
Product Dimensions (with Mount) |
132 × 100 × 180 mm |
|
Product Weight (with Mount) |
668 g |
Application Scenario
It is a rare, high-quality mounting option for multi-rotor drones, VTOL drones, intelligent robots, and other fields.
