Electro-Optical Pod
0102030405
ZR10 Electro-Optical Pod
Product Description
The ZR10 is the first zoom electro-optical pod independently developed and launched by BORAN Technology. It boasts a high resolution of up to 4 million pixels, supporting a maximum of 30x hybrid zoom and 10x optical zoom, along with 2K-level video recording and photography. It can be optionally equipped with the powerful BORAN self-developed AI recognition and tracking function. The gimbal features a rich set of control interfaces, compatible with both BORAN link products and third-party link devices. The high-precision, highly coordinated control algorithm ensures stable zooming and imaging effects during flight. HDR and starlight night vision capabilities expand its use to all-weather scenarios.
Equipment Features
1.30x Hybrid Zoom 10x Optical Zoom
2.2K Full HD Video Recording & Photo Capture
3.4MP 1/2.7-inch CMOS
4.Nose Mode Inverted Mode
5.320°Rotation Range on Yaw Axis
6.Compatible with Ardupilot & PX4 (Mavlink)
7.High-Precision, High-Coordination Control Algorithm
Technical Specifications
|
Category |
Parameter Details |
|
Zoom Camera |
Lens: 10x Optical Zoom (30x Hybrid Zoom) |
|
TF Card Video Recording Resolution: 2K (2560×1440) @ 30 fps |
|
|
Image Sensor: 1/2.7 inch CMOS, Effective Pixels: 4 million |
|
|
Gimbal Horizontal Rotation Range |
-160° ~ +160° |
|
Video Output Signal Interface |
Ethernet |
|
Control Signal Input Method |
S.Bus, UART, Ethernet (UDP) |
|
Product Dimensions |
121 × 101 × 78 mm |
|
Product Weight |
381 g |
Application Scenario
It is a rare, high-quality mounting option for multi-rotor drones, VTOL drones, intelligent robots, and other fields.
