Flight Control System
0102030405
N7 flight controller
Product Description
The N7 flight controller is equipped with the H7 double-precision floating-point unit processor, and features an integrated dual IMU redundancy and shock-absorbing structural design, providing high reliability for the aircraft. The N7 flight controller is compatible with both the Ardupilot and PX4 open-source ecosystems, enabling extensive application expansions. It offers stable and comprehensive system-level solutions for drone, unmanned vehicle, unmanned vessel, and intelligent robotics enthusiasts, as well as industry application explorers.
Equipment Features
1.H7 Dual-Precision Floating-Point Computing Unit Processor
2.High-Performance Low-Noise Automotive-Grade IMU
3.Dual-Redundant IMU
4.Dual-Redundant Magnetometer
5.Internal Vibration Damping Structure
6.Compatible with PX4 & ArduPilot
Technical Specifications
|
Category |
Parameter Details |
|
Main Processor |
STM32H743IIK6 (32 Bit Arm® Cortex®-M7, 480MHz, 2MB Flash, 1MB RAM) |
|
Coprocessor |
STM32F103 (32 Bit Arm® Cortex®-M3, 72MHz, 20KB SRAM) |
|
Accelerometer/Gyroscope |
BMI088/ICM20689 |
|
Electronic Compass |
IST8310 |
|
Barometer |
MS5611 |
|
Supported Models |
PX4 / ArduPilot firmware (Fixed-wing, 3-8 axis multirotor, Helicopter, VTOL, UAV, USV, etc.) |
|
Product Dimensions |
47*68*19mm |
|
Ground Station Weight |
57 g |
