Industrial Drone Series
HX-60 Hydrogen Energy Drones
Product Description
Technical Specifications
|
H601 |
|||
|
Rotor Count |
6 |
Continuous Flight Time with 6kg Payload |
55min |
|
Motor Shaft Distance |
1600mm |
Continuous Flight Time with 5kg Payload |
60min |
|
Empty Weight |
20kg |
Protection Features |
Rainproof, Dustproof |
|
Maximum Take-off Weight |
30kg |
Packaging Dimensions |
1m x 1m x 1m |
|
Payload Capacity |
12kg |
Overall Weight |
< 30kg |
|
Maximum Horizontal Speed |
15m/s |
Wind Resistance |
Not less than Level 8 |
|
Obstacle Avoidance System |
Four-way millimeter-wave radar |
Battery System Type |
Intelligent battery system, 62000mAh single battery pack |
|
Maximum Climb Speed |
5m/s |
Battery Capacity |
62000mAh |
|
Maximum Descent Speed |
3m/s |
Expandability |
Supports a wide range of sensors including LiDAR, cameras, thermal imaging, and multispectral sensors |
|
Altitude Holding Accuracy |
±0.1m |
Ground-based Positioning System Module |
GNSS, RTK/PPK module included |
|
Speed Holding Accuracy |
±0.2m/s |
Obstacle Avoidance Function |
Included |
|
Hovering Accuracy |
±0.1m |
Sensors |
IMU, Magnetometer, GNSS, Multi-sensor system |
